Product Name : AS340 PANTHER
Capacity : 120GB / 240GB / 480GB / 960GB
Interface : SATA 3.2 (6Gb/s)
NAND Flash : 3D NAND
Sequential Read Performance 120GB: Up to 550MB/s
240GB: Up to 550MB/s
480GB: Up to 550MB/s
960GB: Up to 550MB/s
Capacity : 120GB / 240GB / 480GB / 960GB
Interface : SATA 3.2 (6Gb/s)
NAND Flash : 3D NAND
Sequential Read Performance 120GB: Up to 550MB/s
240GB: Up to 550MB/s
480GB: Up to 550MB/s
960GB: Up to 550MB/s
Sequential Write Performance 120GB: Up to 500MB/s
240GB: Up to 520MB/s
480GB: Up to 520MB/s
960GB: Up to 510MB/s
*The performance may vary due to host hardware, software , usage and storage capacity.
240GB: Up to 520MB/s
480GB: Up to 520MB/s
960GB: Up to 510MB/s
*The performance may vary due to host hardware, software , usage and storage capacity.
IOPs (4K Random Write) Up to 80,000
ECC Support Up to 72bit/1KB
Shock 1,500G/0.5msec
Vibration 10~2000Hz/20G
Low Power Consumption 120GB: 1260mW/320mW
(Active/Idle) 240GB: 1450mW/325mW
480GB: 1710mW/315mW
960GB: 2000mW/450mW
(Active/Idle) 240GB: 1450mW/325mW
480GB: 1710mW/315mW
960GB: 2000mW/450mW
MTBF 1,500,000 hours
Humidity 5% ~95%
Standard Operating Temperature 0°C ~ +70°C
Storage Temperature -40 ~ +85°C
Dimensions (L)100 x (W)69.9 x (H)7 mm
Certificate CE, FCC, VCCI, BSMI, RoHS
Warranty 3 Years
*The SSD is based on the TBW or Warranty period.
*The SSD is based on the TBW or Warranty period.
