Product Name : AS2280P4U
Capacity : 256GB / 512GB / 1024GB
Interface : PCIe Gen3 x4
NAND Flash : 3D NAND
Sequential Read Performance Up to 3,500 MB/s
Capacity : 256GB / 512GB / 1024GB
Interface : PCIe Gen3 x4
NAND Flash : 3D NAND
Sequential Read Performance Up to 3,500 MB/s
Sequential Write Performance Up to 3,000 MB/s
*The performance may vary due to host hardware, software , usage and storage capacity.
*The performance may vary due to host hardware, software , usage and storage capacity.
IOPs (4K Random Write) Up to 360,000 IOPS
ECC Support Up to 72bit/1KB
Shock 1,500G/0.5msec
MTBF 1,800,000 hours
Standard Operating Temperature 0°C ~ +70°C
Storage Temperature -40 ~ +85°C
Dimensions Single side : (L)80.00 x (W)22.00 x (H)2.25mm
Double side : (L)80.00 x (W)22.00 x (H)3.5mm
Weight: 6.8g
Double side : (L)80.00 x (W)22.00 x (H)3.5mm
Weight: 6.8g
Certificate CE, FCC, VCCI, BSMI, RoHS
Warranty 5-Year Limited Warranty
*The SSD is based on the TBW or Warranty period.
*The SSD is based on the TBW or Warranty period.
